Next-level track performance
The Dolan DF4 builds upon the success of its predecessor, the game-changer that was the DF3. Having shattered world records and been the winner of over 80 World and European Championship races we’ve returned to the drawing board to dream it all up again.The DF4 has the same geometry as the DF3 but has been engineered for improved performance and handling. 115g lighter and 18% stiffer, we targetted those all-important areas in track cycling where the differences are really made. In a bike design streamlined for performance, in an aero design that’s UCI approved, the DF4 cuts through the air in the heat of competition.Trialled at the European Winter Six Day circuit, the DF4 has already won 3 European and 2 World Championships. And we at Dolan are proud to play a part in the track cycling revolution.
Shop Now

DF4

Features

Aerodynamic Design

Designed to cut through the air with an aero design that gives you an edge on the competition.

UCI Approved Frame & Fork

Take your track game to the next level. The aero design of the DF4 is compatible with current UCI regulations, ensuring you maximise the potential of every watt you produce.

Who is it for?

Those competing at the highest levels are often separated by the finest of margins. When it comes to performing at an elite level in track cycling, it often comes down to the equipment used. The DF4 was developed for those track cyclists who demand the very best in terms of performance and stiffness.

The DF4 targets specific areas to eke out yet more performance over its predecessor. The stiff design ensures maximum power transfer through the pedals with negligible losses. While the lighter design ensures that every watt generated propels you forward ever-more efficiently as you reach the limits of what’s possible.

X-Small
  • 5'3-5'5" - 160-165cm
  • Crank Length: 165cm
  • Stem: 8cm
  • Bar Width: 38cm
Small
  • 5'5-5'7" - 165-170cm
  • Crank Length: 165cm
  • Stem: 9cm
  • Bar Width: 40cm
Medium
  • 5'7-5'9" - 170-175cm
  • Crank Length: 165cm
  • Stem: 10cm
  • Bar Width: 42cm
Large
  • 5'9-6'0" - 175-182.5cm
  • Crank Length: 170mm
  • Stem: 11cm
  • Bar Width: 42cm
X Large
  • 6'0-6'4" - 182.5-193cm
  • Crank Length: 170mm
  • Stem: 12cm
  • Bar Width: 42cm
XX Large
  • 6'0-6'4" - 182.5-193cm
Size 51.5cm 53cm 55cm 57cm 59cm 61cm
A Head Angle 73.5 74.0 74.0 74.0 74.5 74.5
B Head Tube Length (mm) 100 100 120 120 140 140
C Effective Top Tube Horizontal (mm) 515 530 550 570 590 610
D Seat Angle 75.0 75.0 74.5 74.5 75.0 75.0
E Seat Tube Length Center To Top (mm) 460 487 505 505 530 530
F Stack (mm) 477 479 498 498 519 519
G Reach (mm) 393 401 414 434 451 471

FAQS

Want to find out more about The Dolan DF4? What is the warranty? Or What does the DF4 weigh? The Answers to these and more can be found below.

The DF4 frame and fork weighs approximately 2.10kg for a 55cm size frame

All Dolan branded frames and forks purchased after January 1st 2024 carry a lifetime warranty
The DF4 has clearance for 23mm tyres Max.

There are no mounts for bottle cages.

We recommend a maximum rider weight of 120kgs.

The BB shell is a traditional threaded 68mm British type

No,the frame and forks doesn't have mounting points for caliper brakes.

They are horizontal so you can adjust chain tension and wheelbase length.

Due to the many different systems people use we do not supply pedals with bikes.

(3)
Sort By
  • Low to High
  • High to Low
  • A to Z
  • Z to A
  • New In
£2254.98
Dolan DF4 Carbon Track Bike - Alpina
£38.54 per month on finance
£2999.99
Dolan DF4 Carbon Track Bike - Alpina-SE
£40.96 per month on finance
£2604.98
Dolan DF4 Carbon Track Bike - Sugino-SG75
£35.58 per month on finance
You've viewed 3 of 3 products
